Name: Atomos Shogun (V1)
SKU: 1164
Availability: InStock

Description

The original Atomos Shogun V1 is a professional 7-inch touchscreen field monitor and external recorder designed to provide high-quality recording and monitoring from compatible HDMI and SDI cameras.

Originally introduced as a professional 4K external recorder, the Shogun V1 can record compatible camera signals in Apple ProRes and Avid DNx formats, while also supporting selected RAW workflows. It accepts HDMI and 4K SDI inputs and provides professional monitoring tools including waveform, RGB parade, vectorscope, focus peaking, zebra, and 3D LUT support.

The Shogun V1 is particularly useful for productions that want to bypass a camera’s internal recording limitations and capture a high-quality editing codec directly from the camera.

Key Features

7.1″ Professional Touchscreen

The Shogun V1 features a 7.1-inch 1920 × 1200 SuperAtom IPS touchscreen with a Rec.709 color standard.

The large display provides significantly more viewing area than a typical camera LCD, making it useful for checking focus, exposure, framing, and image quality during production.

The touchscreen interface provides direct access to recording, monitoring, playback, exposure tools, and other camera-assist functions.

4K Recording

The Shogun V1 was designed around the emerging 4K production workflow and can record compatible 4K UHD signals up to 30p.

Supported recording formats include:

The exact RAW capabilities depend on the connected camera and supported firmware.

HD High-Frame-Rate Recording

In addition to 4K recording, the original Shogun can handle high-frame-rate HD signals, including 1080p up to 120 fps with compatible camera outputs.

This makes it useful for:

Actual available frame rates depend on the camera and signal being supplied to the recorder.

HDMI and SDI Connectivity

The Shogun V1 provides both HDMI and professional SDI connectivity.

HDMI

The HDMI input supports compatible HD and 4K signals through HDMI 1.4b, including 4K up to 30p.

SDI

The unit includes a 4K-capable SDI input/output interface supporting professional SDI formats.

The Shogun can also perform HDMI-to-SDI and SDI-to-HDMI conversion, allowing it to act as a useful signal-conversion device on set.

Professional Monitoring Tools

The Shogun V1 includes a variety of tools designed to help camera operators and cinematographers evaluate their image.

Waveform

Monitor luminance levels and evaluate exposure throughout the image.

RGB Parade

Analyze individual red, green, and blue channels for exposure and color balance.

Vectorscope

Evaluate hue and saturation information.

Focus Peaking

Highlight areas of the image that are in focus to assist with manual focusing.

Zebra

Provide exposure warnings at user-selected thresholds.

3D LUT Support

Load compatible .cube LUT files for monitoring Log footage with a viewing LUT or creative look.

These tools make the Shogun useful as both a recorder and dedicated camera-assist monitor.

RAW Recording

One of the original Shogun’s major selling points was its ability to work with compatible cameras capable of outputting RAW video.

Supported RAW workflows included cameras such as the Sony FS700 and other compatible systems, depending on firmware and camera configuration.

RAW compatibility should be verified for the specific camera before rental because support depends on the camera, output format, firmware, and Shogun firmware.

Audio Recording

The Shogun V1 provides professional audio connectivity through its XLR breakout system.

It supports:

This allows the Shogun to function as a combined video and audio recording device when required.

Camera Triggering

The Shogun can receive recording triggers from compatible cameras through HDMI or SDI.

Supported camera-control protocols include compatible Canon, Sony, and Atomos recording-control systems.

This allows the external recorder to start and stop recording along with the camera rather than requiring the operator to manually trigger both devices.

Recording Media

The original Shogun uses Atomos Master Caddy II media carriers and compatible SATA-based storage.

Depending on the specific rental package, the recorder can be supplied with compatible SSD or other approved recording media.

For rental customers, KR Camera Rental can provide the Shogun with recording media as an optional package upgrade.

Power

The Shogun V1 is designed for field production and supports NP-series batteries as well as D-Tap power through the appropriate cable.

The operating voltage range is approximately 6.2–16.8V.

Battery runtime depends heavily on battery capacity, recording resolution, frame rate, display brightness, and whether the unit is simultaneously monitoring and recording.

Applications

Cinema Production

Use the Shogun as an external recorder for cameras that provide higher-quality HDMI or SDI output than their internal recording system.

Commercial Production

The large monitor and professional recording codecs make the Shogun useful for commercial and branded-content production.

Documentary and Interview Production

The recorder can provide high-quality external recording while giving the camera operator a larger monitoring screen.

Sports and Slow Motion

HD high-frame-rate recording makes the Shogun useful for compatible slow-motion workflows.

Camera Department

The waveform, vectorscope, focus peaking, and LUT tools provide useful image-analysis capabilities for camera operators and assistants.

Atomos Shogun (V1)
